ATHL-MLB

Athena Mini Lite Beam

1"thick edge-lit acrylic lens. Extruded aluminum housing w/welded end-plates.  LED optimized optics for smooth, efficient illumination. Programmable driver for custom lumen packages. 0-10V dimming to 1% standard or Dim-to-Off. DMX, Lutron and DALI protocols also available. Sensor Ready for wireless Smart Lighting Solutions. 80/90CRI, Tunable White, RGBW & RGBWW. Bios SkyBlueTM circadian solutions available.
Specification Sheet

Resources

CONSTRUCTION: Extruded aluminum housing. 20 gauge cold rolled steel internal components.

REFLECTOR: Die-formed steel finished in highly reflective baked white enamel with pre-finished reflective LED tray.

OPTICS: 1" thick cast clear acrylic with frosted edges.  Custom laser engraving is also available. Contact factory for details.

LED: Static white LED modules in 27/30/35/40 & 50K CCT, 80/90CRI. Lumen maintenance minimum L70= 50,000 hours. 3 SDCM color consistency. BIOS SkyBlue, RGB, RGBW, RGBWW. Tunable White and Dim-to-Warm options available.

DRIVER: Standard driver is Class 2 AOC 0-10V to 1%, Dim-to-Off available. 120/277V input, PF > 90%, THD < 20 @ 120V. Additional dimming protocols available. All drivers prewired from factory for connection to control system (by others), field replaceable.

MOUNTING: Standard suspension options include adjustable self-locking aircraft cables (AC), and rigid pendant stems (PD). AC assembly is 48" x 1/16" with a 5" feed canopy and 2" suspension canopies. 18 gauge power and 22 gauge dimming control SJT feed. May also be installed in Grid (G) and plaster ceilings in either Flanged (F) or Trimless (TRL) configurations, and wall mount with 1/4" stand-off brackets.

FINISH: Finished in baked white enamel. Canopies and pendant stems are white enamel unless otherwise specified.

CERTIFICATION: Luminaires are cETLus listed conforming to UL STD. 1598 and certified to CSA STD C22.2 NO. 250.0. Suitable for dry & damp locations. Union Made in the United States of America. I.B.E.W., BAA compliant, Declare Red List Approved.

Mounting

  • Recessed
  • Surface
  • Suspended
  • Wall

Distribution

  • Direct

Ratings & Compliance

  • Buy American Act (BAA)
  • Declare
  • Made in America
  • Red List Approved

Lumens

  • 260 Lm
  • 350 Lm
  • 450 Lm

Emergency Options

  • EM Circuit
  • GTD
  • Integral EM Battery

Controls Options

  • Daylight Sensor
  • Occupancy Sensor
  • Wireless Control

Dimming Protocol

  • DALI
  • DMX
  • Lutron

Dimming Range

  • 1%
  • 5%
  • < 1%

Dynamic LED Color

  • BIOS Dynamic
  • RGB
  • RGBW
  • RGBWW
  • Tunable White

Wiring Options

  • DMX Harness

CCT

  • 2700K
  • 3000K
  • 3500K
  • 4000K
  • 5000K
  • 6500K

CRI

  • 80 CRI
  • 90 CRI

Color / Finish

  • Anti-Microbial White
  • Custom
  • White

Efficacy

  • 50 lm/w

Integrated Brands

  • Acuity nLight
  • Avi-on
  • BubblyNet
  • Casambi
  • Cooper Wavelinx
  • Current NX
  • Encelium
  • Enlightened
  • Legrand
  • Lutron Athena
  • Lutron Vive
  • Philips EasySense

Lamp Source

  • LED

Listings

  • CSA
  • UL
  • cETLus

Materials

  • Acrylic
  • Aluminum
  • Steel

Static LED Color

  • BIOS Static
  • White

Voltage

  • 120 V
  • 277 V
  • 347 V

Watts

  • 2 w
  • 3 w
  • 4 w
  • 5 w
  • 7 w
  • 9 w
  • 10 w
  • 12 w
