PRFL-24-DI
OMNI Hospital_PRFL-24.jpgPRFL-24-DI
Profile 24 Direct / Indirect DLC
PRFL-24 is crafted from precision-extruded aluminum with welded end caps, offering a sleek, architectural form that integrates effortlessly into contemporary commercial spaces. Designed to enhance environments such as offices, classrooms, healthcare facilities, and other high-traffic areas, this fixture combines aesthetic appeal with durability.
Offered in individual fixtures up to 8’ or continuous rows for seamless integration, PRFL-24 is available in suspended or surface-mounted configurations. It supports cutting-edge Smart Lighting solutions, including daylight harvesting, occupancy sensing, and integrated wireless controls, enabling energy-efficient and responsive lighting management.
Resources
CONSTRUCTION: Extruded aluminum housing. 20 gauge cold rolled steel internal components.
REFLECTOR: Highly reflective baked white enamel with pre-finished reflective LED tray.
OPTICS: Direct opal acrylic Flush lens is standard. 1" acrylic Drop lens, Steel Cross Baffle with acrylic overlay optional. Indirect Clear Acrylic dust covers standard, Flush lens, Satin Ice, Asymmetrical, Batwing, Collimating and Black Out lenses available.
LED: Static white LED modules in 30/35/40 & 50K CCT, 80/90CRI. Lumen maintenance minimum L70= 50,000 hours. 3 SDCM color consistency. BIOS SkyBlue, RGB, RGBW, RGBWW, Advanced Color, Tunable White and Dim-to-Warm options available; field replaceable.Â
DRIVER: Standard driver is Class 2 AOC 0-10V to 1%, Dim-to-Off available. 120/277V input, PF > 90%, THD < 20 @ 120V. DMX, DALI & Lutron protocols available. All drivers prewired for connection to control system (by others); field replaceable.Â
MOUNTING: Standard options include adjustable self-locking aircraft cables (AC), and rigid pendant stems (PD). AC assembly is 48" x 1/16" with a 5" feed canopy and 2" suspension canopies. 18 gauge power and 22 gauge dimming control SJT feed.Â
FINISH: Housing and components finished in baked white enamel. Canopies and pendant stems are white enamel unless otherwise specified. 5" Feed canopy w/2" Suspension canopies.
CERTIFICATION: cETLus listed conforming to UL STD. 1598 and certified to CSA STD C22.2 NO. 250.0. Suitable for dry & damp locations. Union Made in the United States of America. I.B.E.W., BAA compliant, DLC V5.1 Standard Listed. Declare Red List Approved.Â
Mounting
- Suspended
Distribution
- Direct/Indirect
Ratings & Compliance
- Buy American Act (BAA)
- DLC
- Declare
- Made in America
- Red List Approved
Special Programs
- Rapid Ship
Lumens
- 1169 Lm
- 1558 Lm
- 1947 Lm
Emergency Options
- EM Circuit
- GTD
- Integral EM Battery
Controls Options
- Daylight Sensor
- Occupancy Sensor
- Wireless Control
Dimming Protocol
- DALI
- DMX
- Lutron
Dimming Range
- 1%
- 5%
- < 1%
Dynamic LED Color
- BIOS Dynamic
- RGBW
- RGBWW
- Tunable White
Wiring Options
- DMX Harness
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
- 6500K
CRI
- 80 CRI
- 90 CRI
Color / Finish
- Anti-Microbial White
- Custom
- White
Efficacy
- 122 lm/w
- 123 lm/w
- 127 lm/w
Integrated Brands
- Acuity nLight
- Avi-on
- BubblyNet
- Casambi
- Cooper Wavelinx
- Current NX
- Encelium
- Enlightened
- Legrand
- Lutron Athena
- Lutron Vive
- Philips EasySense
Lamp Source
- LED
Listings
- CSA
- UL
- cETLus
Materials
- Acrylic
- Aluminum
- Steel
Static LED Color
- BIOS Static
- White
Voltage
- 120 V
- 277 V
- 347 V
Watts
- 3 w
- 4 w
- 5 w
- 9 w
- 10 w
- 12 w
- 13 w
- 16 w
