PRFL-44-D-G
Screenshot 2024-07-24 at 1.05.10 PM.pngPRFL-44-D-G
Profile 44 Direct Grid
PRFL-44’s architectural design, crafted from precision-extruded aluminum with welded end caps, makes it an ideal lighting solution for modern commercial environments. Perfect for office spaces, classrooms, and healthcare facilities, this fixture offers both form and function.
Available as individual fixtures up to 8' or in continuous rows for grid ceiling applications, PRFL-44 integrates seamlessly with Armstrong ceiling systems. Compatible with advanced Smart Lighting technologies like daylight harvesting, occupancy sensing, and wireless control systems, this fixture enhances lighting performance while maintaining an aesthetically refined presence.
Resources
CONSTRUCTION: Extruded aluminum side housing. 20 gauge cold rolled steel top and internal components.
REFLECTOR: Highly reflective baked white enamel with pre-finished reflective LED tray.
OPTICS: Flush opal acrylic lens is standard.
LED: Static white LED modules in 30/35/40 & 50K CCT, 80/90CRI. Lumen maintenance minimum L70= 50,000 hours. 3 SDCM color consistency. BIOS SkyBlue, RGB, RGBW, RGBWW, Advanced Color, Tunable White and Dim-to-Warm options available; field replaceable.Â
DRIVER:Â Class 2 AOC 0-10V to 1%, Dim-to-Off available. 120/277V input, PF > 90%, THD < 20 @ 120V. DMX, DALI & Lutron protocols available. All drivers prewired for connection to control system (by others); field replaceable.Â
MOUNTING: Standard mounting is in suspended grid ceilings.Â
FINISH: Housing and components finished in baked white enamel.Â
CERTIFICATION: cETLus listed conforming to UL STD. 1598 and certified to CSA STD C22.2 NO. 250.0. Suitable for dry & damp locations. Union Made in the United States of America. I.B.E.W., BAA compliant, Declare Red List Approved.
Mounting
- Recessed
Distribution
- Direct
Ratings & Compliance
- Buy American Act (BAA)
- Declare
- Made in America
- Red List Approved
Special Programs
- Rapid Ship
Lumens
- 510 Lm
- 680 Lm
- 825 Lm
Emergency Options
- EM Circuit
- GTD
- Integral EM Battery
Controls Options
- Daylight Sensor
- Occupancy Sensor
- Wireless Control
Dimming Protocol
- DALI
- DMX
- Lutron
Dimming Range
- 1%
- 5%
- < 1%
Dynamic LED Color
- BIOS Dynamic
- RGBW
- RGBWW
- Tunable White
Wiring Options
- DMX Harness
- Flexible Whip
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
- 6500K
CRI
- 80 CRI
- 90 CRI
Color / Finish
- Anti-Microbial White
- Custom
- White
Efficacy
- 92 lm/w
- 98 lm/w
Integrated Brands
- Acuity nLight
- Avi-on
- BubblyNet
- Casambi
- Cooper Wavelinx
- Current NX
- Encelium
- Enlightened
- Legrand
- Lutron Athena
- Lutron Vive
- Philips EasySense
Lamp Source
- LED
Listings
- CSA
- UL
- cETLus
Materials
- Acrylic
- Aluminum
- Steel
Static LED Color
- BIOS Static
- White
Voltage
- 120 V
- 277 V
- 347 V
Watts
- 3 w
- 4 w
- 5 w
- 7 w
- 9 w
- 10 w
- 12 w
