PRFL-24-DI-WM

Profile 24 Direct / Indirect Wall DLC

PRFL-24’s clean, architectural design is ideal for spaces requiring ADA compliance, such as offices, classrooms, and healthcare facilities. Manufactured from precision-extruded aluminum with welded end caps, it offers an aesthetically refined solution that aligns with modern commercial interiors.

Available as individual fixtures up to 8' or in continuous rows for wall-mounted applications, PRFL-24 supports advanced Smart Lighting technologies, such as daylight harvesting, occupancy sensing, and integrated wireless controls, providing versatility and sustainability in any environment.
Specification Sheet

Resources

BIM & CAD Files


Share Links
Download
CONSTRUCTION: Extruded aluminum housing. 20 gauge cold rolled steel internal components.

REFLECTOR: Die-formed steel finished in highly reflective baked white enamel with pre-finished reflective LED tray.

OPTICS: Direct opal acrylic Flush lens is standard. 1" acrylic Drop lens, Steel Cross Baffle with acrylic overlay optional. Indirect Clear acrylic dust covers standard, Flush lens, Satin Ice, Asymmetrical, Batwing, Collimating and Black Out lenses available.

LED: Static white LED modules in 27/30/35/40 & 50K CCT, 80/90CRI. Lumen maintenance minimum L70= 50,000 hours. 3 SDCM color consistency. BIOS SkyBlue, RGB, RGBW and Tunable White and Advanced Color options available.

DRIVER: Standard driver is Class 2 AOC 0-10V to 1%, 120/277V input, PF > 90%, THD < 20 @ 120V. Additional dimming protocols available. All drivers prewired from factory for connection to control system (by others). Field replaceable.

MOUNTING: Standard installation is wall mount with included mounting brackets and hardware. Requires single-gang j-box supplied by others.

FINISH: Housing and components finished in baked white enamel.

CERTIFICATION: cETLus listed conforming to UL STD. 1598 and certified to CSA STD C22.2 NO. 250.0. Suitable for dry & damp locations. Union Made in the United States of America. I.B.E.W., BAA compliant, DLC V5.1 Standard Listed. Declare Red List Approved.

Mounting

  • Wall

Distribution

  • Direct/Indirect

Ratings & Compliance

  • ADA
  • Buy American Act (BAA)
  • DLC
  • Declare
  • Made in America
  • Red List Approved

Special Programs

  • Rapid Ship

Lumens

  • 1155 Lm
  • 1540 Lm
  • 1590 Lm
  • 1900 Lm

Emergency Options

  • EM Circuit
  • GTD
  • Integral EM Battery

Controls Options

  • Daylight Sensor
  • Occupancy Sensor
  • Wireless Control

Dimming Protocol

  • DALI
  • DMX
  • Lutron

Dimming Range

  • 1%
  • 5%
  • < 1%

Dynamic LED Color

  • BIOS Dynamic
  • RGBW
  • RGBWW
  • Tunable White

Wiring Options

  • DMX Harness

CCT

  • 2700K
  • 3000K
  • 3500K
  • 4000K
  • 5000K
  • 6500K

CRI

  • 80 CRI
  • 90 CRI

Color / Finish

  • Anti-Microbial White
  • Custom
  • White

Efficacy

  • 116 lm/w
  • 118 lm/w
  • 121 lm/w
  • 122 lm/w

Integrated Brands

  • Acuity nLight
  • Avi-on
  • BubblyNet
  • Casambi
  • Cooper Wavelinx
  • Current NX
  • Encelium
  • Enlightened
  • Legrand
  • Lutron Athena
  • Lutron Vive
  • Philips EasySense

Lamp Source

  • LED

Listings

  • CSA
  • UL
  • cETLus

Materials

  • Acrylic
  • Aluminum
  • Steel

Static LED Color

  • BIOS Static
  • White

Voltage

  • 120 V
  • 277 V
  • 347 V

Watts

  • 3 w
  • 4 w
  • 5 w
  • 7 w
  • 10 w
  • 12 w
  • 13 w
