ELTL-3-DI-WMELTL-3-DI-WM
Elite 3 Direct / Indirect Wall
ELTL-3 wall mount is a linear luminaire system with an efficient, decorative design traditionally used in educational, healthcare, municipal and similar interiors for general illumination. Available in a predominately indirect distribution, the ELTL-3 series is a narrower alternative to the ELTL-1 series. A suspended companion piece is also available.
Â
Compatible with a range of advanced Smart Lighting technologies, including daylight harvesting, occupancy sensing, and integrated wireless controls. May be specified with static or tunable white CCT, Dim-to-Warm or RGBW color options, and a variety of emergency options.
Resources
CONSTRUCTION: Die-formed, 20-gauge, cold rolled steel.Â
REFLECTOR: Highly reflective, die-formed steel finished in baked white enamel is standard. Consult factory for high efficiency options.
OPTICS: Standard shielding for center and side lenses is LED optimized Satin Ice Acrylic.Â
LED: Static white LED modules in 27/30/35/40 & 50K CCT, 80/90CRI. Lumen maintenance minimum L70= 50,000 hours. 3 SDCM color consistency. BIOS SkyBlue, RGB, RGBW, RGBWW. Tunable White and Dim-to-Warm options available.Â
DRIVER: Standard driver is Class 2 AOC 0-10V to 1%, Dim-to-Off available. 120/277V input, PF > 90%, THD < 20 @ 120V. Additional dimming protocols available. All drivers prewired from factory for connection to control system (by others), field replaceable.
MOUNTING: Standard installation is direct to junction box or conduit feed. Mounting holes provided for additional supporting hardware (supplied by others).
FINISH: Fixture housing and steel components are finished in baked white enamel applied over a five-stage pretreatment process. Canopies and pendant stems are white enamel unless otherwise specified.
CERTIFICATION: Luminaires are cETLus listed conforming to UL STD. 1598 and certified to CSA STD C22.2 NO. 250.0. Suitable for dry & damp locations. Union Made in the United States of America. I.B.E.W., BAA compliant, Declare Red List Approved.
Mounting
- Wall
Distribution
- Direct/Indirect
Ratings & Compliance
- Buy American Act (BAA)
- Declare
- Made in America
- Red List Approved
Emergency Options
- EM Circuit
- GTD
- Integral EM Battery
Controls Options
- Daylight Sensor
- Occupancy Sensor
- Wireless Control
Dimming Protocol
- DALI
- DMX
- Lutron
Dimming Range
- 1%
- 5%
- < 1%
Dynamic LED Color
- BIOS Dynamic
- RGBW
- RGBWW
- Tunable White
Wiring Options
- DMX Harness
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
- 6500K
CRI
- 80 CRI
- 90 CRI
Color / Finish
- Anti-Microbial White
- Custom
- White
Efficacy
- 112 lm/w
- 125 lm/w
Integrated Brands
- Acuity nLight
- Avi-on
- BubblyNet
- Casambi
- Cooper Wavelinx
- Current NX
- Encelium
- Enlightened
- Legrand
- Lutron Athena
- Lutron Vive
- Philips EasySense
Lamp Source
- LED
Listings
- CSA
- UL
- cETLus
Materials
- Acrylic
- Steel
Static LED Color
- BIOS Static
- White
Voltage
- 120 V
- 277 V
- 347 V
Watts
- 2 w
- 3 w
- 4 w
- 5 w
- 7 w
- 9 w
- 10 w
- 12 w
